Specifications
| Cell Type | Mono Cell |
| Peak Power | 100W |
| Vmp | 18V |
| Imp | 5.5A |
| Maximum System Voltage | 1000V |
| Voc | 22.5V |
| Isc | 6.6A |
| Tolerance | ±5% |
| Conversion efficiency | 22%~23.4% |
| Output Port | MC4 1m |
| Unfolded Size | 1250*600*25mm |
| Folded Size | 400*600*50mm |
| Net Weight | 4.5 KG |
| Total transmittance | 95% |
| Working temperature |  -20℃～60℃ |
| Maximum power temperature Coefficient |
 -0.45%/℃ |
| Open circuit voltage temperature coefficient |
 -0.35%/℃ |
| Temperature coefficient of short circuit current |
 +0.05%/℃ |
| Test standard conditions | Am1.5 25℃ 1000W/㎡ |
| Moisture permeability | 40℃/90%RH g/M².Day 10.2 |
| Water absorption rate | 2.5%(24H) |
| Remarks | Testing environment (STC)： Spectral energy： 1KW/㎡ Air pressure AM=1.5 , The light conditions are 38000W Lux（ Lighting unit ） Electronic load test. |
